Screw-Lock Molded Cable Assemblies
Vibration-proof cordsets that hold the connector mated with a threaded coupling instead of a friction latch, covering D-Sub DB9 / DB15 / DB25, M23 servo, GX16 aviation, VGA, DVI and locking USB-C. Sealed IP67 and panel-mount builds available; pinout and shell size set per order.
- Locking
- 4-40 UNC · M3 · M12 coupling
- Interface
- D-Sub · M23 · GX16 · USB-C
- Legacy video
- VGA HD15 · DVI-D · DVI-I
- Fieldbus
- RS-485 · Modbus RTU · CAN
- Servo
- M23 power + encoder feedback
- Sealing
- IP67 on request
- Overmold
- PVC · PUR strain relief
- Length
- 0.3 m – 20 m
Specification table
A friction-fit plug eventually walks out under vibration, and a cable that snags in a service aisle pulls out faster. These assemblies replace that retention with a mechanical lock: a thumbscrew into a panel receptacle, a jackscrew on a D-Sub shell, or a threaded collar on a circular connector.
| Parameter | Standard build | Available on request |
|---|---|---|
| Locking method | 4-40 UNC thumbscrew, M2.5 / M3 thumbscrew | Jackscrew on D-Sub shells, threaded collars |
| Interface | D-Sub and DB9, USB-C, HDMI, RJ45 | VGA HD15, DVI-D, DisplayPort, GX16 aviation, M23 servo |
| Fieldbus | RS-485 Modbus RTU, CAN, DeviceNet ready lead Types | Profibus-style terminations on request |
| Servo builds | M23 power plus encoder feedback combinations | Brake pair and shielded feedback pairs in one jacket |
| Overmold material | PVC (cabinet runs), PUR (oil and coolant) | Low-profile bodies where clearance is tight |
| Strain relief | Molded at both ends with an internal clamp | Extended boot, bend-limiting tail |
| Screw hardware | Zinc-plated steel as standard | Stainless, captive panel screws |
| Sealing | IP67 with the matching panel receptacle | Gasketed versions for outdoor enclosures |
| Length | 0.3 m to 20 m | Any length with stated bend radius |
| Hardware kit | Screws supplied fitted | Spare screws, captive washers, labeled kits |
Screw threads follow the ISO metric screw thread series; USB, HDMI and servo interfaces keep to their own governing specifications: USB-IF, HDMI and EMVA for vision interfaces.
