Nurse Call Bedside Cable, Sealed Button, RJ45

Q: What is the minimum order?

Minimum for a prototype run is 5 pcs, out the door in 3 working days. Volume production starts at 500 pcs and ships 14 working days after you approve the sample.

Overview

A nurse call bedside cable lives the hardest life of any lead in a ward. It gets wiped down several times a shift with alcohol based agents, it gets pulled by patients and caught in bed rails, and it is expected to work first time, every time, for years. This range covers the retrofit path from the old 6P4C handset leads to sealed call points that connect over structured cabling or over USB, and it is built for the cleaning regime rather than for the catalog.

Key Specifications

Product type	Nurse call bedside lead with sealed call button
Host end	USB-C or RJ45, straight or right angle
Patient end	Sealed push button unit, IP65 target – to be confirmed
Jacket material	TPU, selected for cleaning agent exposure
Optional section	Coiled section for bedside reach
Length range	1 m to 5 m
Pull resistance	Load path through the molding – force figure to be confirmed
Labeling	Ward and bed tag printing available
Compatibility	Interconnect only, not a medical device or certified accessory

What kills a bedside lead

Replacement programs usually start because the existing leads fail in one of four predictable ways. Each one has a design answer, and the answer is cheap at design stage and expensive afterwards:

Stress in service	Observed failure	Design answer
Repeated wipe-down	Jacket crazes and stiffens, then splits at the strain relief	TPU compound selected for cleaning agent contact
Patient pull on the lead	Terminations take the load and the link goes intermittent	Load path carried by the molding, not by the solder joints
Fluid at the call button	Moisture into the switch housing, false calls or no call	Sealed molded housing with the sealing level quoted per build
Bed rail and trolley crush	Conductor break at the plug exit	Right-angle host end and a coiled section that retracts

Sealing at the button end

The sealing level of the button end is quoted at IP65 in the source material and is treated here as a target until an ingress test report is in hand. IP ratings are defined by IEC 60529: the first digit covers solid ingress and 6 means dust-tight, the second covers liquid and 5 means low-pressure water jets from any direction. For a bedside unit that is wiped rather than hosed, that is usually the right level, but the number your assembly is built and verified to is the one stated on your drawing.

These assemblies are interconnect products for use inside a nurse call installation that the hospital or the integrator qualifies as a complete system. They are not presented as medical devices or as certified medical accessories, and we do not imply any approval we do not hold.

Cleaning agents: test against what the ward actually uses

Wards use different agents and different contact times, and that variability is the reason we will not print a generic wipe-cycle number. A TPU compound that survives quaternary ammonium at a short contact time can still craze under a chlorine based agent left wet on the surface. The only sensible approach is to test against the agent the customer actually uses, at the contact time the protocol specifies. Send the agent list with the enquiry and we will build the test into the sample stage.

Retrofit practice

Most sites run a phased replacement, one ward at a time, reusing the existing back box and outlet plate where the mechanical fit allows. That makes two things the first items to confirm on any enquiry, before length, color or button style:

Outlet geometry – the plate and back box you already have, photographed from the front and with the plate removed.
Pinout – whether the call and any lighting or audio conductors land where the new assembly expects them.
Host interface – structured cabling with RJ45, or USB-C on newer bedhead units.
Reach – whether a coiled section is needed so the lead does not loop onto the floor.

Send a photograph of the existing outlet and we will match it. Where the site runs mixed estates, our nurse call button cable with 6P4C plug covers the older sockets still in service.

Typical applications for this nurse call bedside cable

Acute ward bedhead units where the existing handset lead is being replaced with a sealed call point
Retrofit programs running one ward at a time, matched to the existing outlet plate
New builds connecting over structured cabling, alongside our nurse call 2-key button cable with silicon coil
Bedhead service panels and monitor carts built up as a medical panel feedthrough set
Assessment and treatment rooms where the lead is wiped down between every patient

The systems these connect into are generally described as nurse call installations; the interface and the protocol are set by the system maker, and we build the lead to the pinout you give us.

Workmanship and testing

Build standard for Nurse Call Bedside builds is IPC/WHMA-A-620 Class 3 under ISO 9001, with terminations from 32 to 12 AWG. No Nurse unit is packed until 100% continuity and pinout check out, and seal checking is quoted whenever an ingress rating is on the drawing.

Every production run can ship with RoHS and REACH declarations and the electrical report agreed at quotation; see certifications and material declarations. UL styles and other named approvals are built to drawing: we source to the style you specify and document it, rather than asserting a listing we do not hold. This assembly is built on the four lines covered under the assembly lines behind this build, with nothing in the build handed to an undisclosed subcontractor. More background: what medical builds require beyond the cable. Tooling is quoted separately, cut in-house rather than brokered out, and owned by you.

Custom builds and ordering

On Nurse Call Bedside builds, prototype lots run from 1 to 50 pcs and leave in 3 working days. Production runs of 500 pcs and up ship 14 working days after approval. Tooling not already held adds around 10 working days. Nurse builds go out under your part number and labeling, and material certificates and first-article reports come with them on request.

Related assemblies

Full range: signal and data cables.

Frequently Asked Questions

Can you match the outlet we already have?

Usually yes. Send a photograph of the outlet plate and, if possible, one with the plate removed so we can see the back box and the existing termination.

Is the call button sealed?

It is a sealed molded housing built to an IP65 target. That figure is pending an ingress test report, so the rating your assembly is verified to is the one we agree on your drawing.

Do you supply the bedhead electronics?

No. This is the interconnect between the call point and the system. The system maker qualifies the installation as a whole.

What is the minimum order?

On Nurse Call Bedside builds, prototype lots run from 1 to 50 pcs and leave in 3 working days. Production runs of 500 pcs and up ship 14 working days after sample approval.
